1.25G 20KM Network SFP Transceiver Module Fiber Optic LC Connector GLC-LH-SM

Name: 125G 20KM Network SFP Transceiver Module Fiber Optic LC Connector GLCLHSM
Brand: HILINK
Price: 1 USD

Buy cheap 1.25G 20KM Network SFP Transceiver Module Fiber Optic LC Connector GLC-LH-SM product

Brand Name : HILINK

Model Number : HLSP3112L-CD20

Certification : CE FCC Rohs

Place of Origin : Guangdong, China

MOQ : 1pcs

Payment Terms : T/T, Western Union

Supply Ability : 10000pcs/ week

Delivery Time : 1-3 days

Packaging Details : Blister Packaging, 10pcs/ tray

Optical Power (dBm) : -8~-1

Wavelength (nm) : 1310nm

Distance : 20km

Source : FP

Sensitivity (dBm) : <-22

Receiver : PIN

DDM : Yes

VHLtage (V) : 3.3

Price : Negotiable

Contact Now

1.25G 20KM Network SFP Transceiver Module Fiber Optic LC Connector GLC-LH-SM

Features

Data-rate of 1.25Gbps/1.063Gbps operation
20km with 9/125 µm SMF
Hot-pluggable SFP footprint duplex LC connector Interface
Class 1 FDA and IEC60825-1 Laser Safety Compliant
Compatible with SFP MSA
Compatible with SFF-8472
+3.3V single power supply and TTL Logic Interface
Average Output Power: -8 ~-4 dBm
Receiver Sensitivity: -22dBm
Extended temperature range (EXT): -5 to 85°C
Built-in Digital Diagnostic Function

Applications

Gigabit Ethernet
Fiber Channel Switch Infrastructur
Other optical transmission systems

STANDARD

SFP MSA (Version Sept.14 2000) compliant
SFF-8472 (Rev 9.3, Aug. 2002) Digital Diagnostic Monitoring Interface for Optical Transceivers compliant
IEEE 802.3z compliant
ANSI specifications for Fiber Channel compliant
Telcordia GR-468-CORE compliant

Specifications:

P/N	GLC-LH-SMD / SFP-GEL
Datarate	1.25G
Distance	20KM
Wavelength	1310nm
Transmitter	FP
Receiver	PIN
Media	SMF
DDM/DOM	YES
Connector	LC
Application	GE
Operating Temperature	-10℃~ +85℃
Voltage Supply	3.3V
Certification	CE/FCC/RoHS/TUV/UL
Brand	Neutral, and OEM

Package Dimensions

1.25G 20KM Network SFP Transceiver Module Fiber Optic LC Connector GLC-LH-SM

Absolute Maximum Ratings

Parameter	Symbol	Unit	Min	Max
Storage Temperature Range	Ts	℃	-40	+85
Relative Humidity	RH	%	5	95
Power Supply Voltage	Vcc	V	-0.5	+4

Recommended Operating Conditions

Parameter	Symbol	Unit	Min	Typ	Max
Storage Temperature Range	Ts	℃	-10		70
Power Supply Voltage	Vcc	V	3.135		3.465
Data Rate		Gb/s	-	1.25	-

Technical Specification

Parameter	Symbol	Unit	Min	Typ	Max	Notes
Electrical Characteristics
Supply Current(TX+RX)	Icc	mA			300
Single Ended Data Input Swing		mV	150		1100
Single Ended Data Output Swing		mV	300		600
TX_fault/LOS output(TTL)	Voh	V	2.0		Vcc
TX_fault/LOS output(TTL)	Vol	V	0		0.8
TX_disable input(TTL)	Voh	V	2.0		Vcc
TX_disable input(TTL)	Vol	V	0		0.8
